Czech LED luminaires manufacturer

LINE HR 4G

Narrow LED Surface mounted luminaires

ZCLED4G39L840/LINE-HR-MIKRO-C




    Variant

SKU: ZCLED4G39L840/LINE-HR-MIKRO-C Categories: ,

Luminaires are suitable for offices, office spaces, school classes and stores.

The luminaire body is made of white-coated steel metal. These luminaires are designed for mounting on solid ceilings or suspending on wire pendants. They can be mounted directly on usual inflammable surfaces.

The optical part of the luminaire consists of a microprismatic diffuser creating homogeneous light without visible LED points.

If the luminaire is dimmable, it is dimmable by DALI digital system.

If it is equipped with an autonomous emergency module it is .

Luminaire is equipped with high quality LEDs Samsung powered by drivers only from renowned manufacturers such as Helvar, Tridonic, OSRAM, TCI. The light source and ballast in this luminaire may only be replaced by the manufacturer or his contracted service technician or similarly qualified person.

We have been producing luminaires suitable for illuminating administrative areas, schools, offices and shops for over 20 years. Give your employees, students, patients and customers a well illuminated space thanks to our luminaires.

Installed LED modules in the luminaire 2x LED 15i60-840
Dimension 90x1150x65 mm
Power 39 W *
Luminous flux 2585 lm
Instalation Surface mounted
Mounting holes (AxBxC) 52x1000 mm
Protection IP 20
Color rendering index CRI > 80
Light colour CCT 4000 K
Ambient temperature 25 ˚C
Lifetime LED: 50.000 h L90B20 - 100.000 h L80B50
Weight 1 kg,2

Luminaires are suitable for offices, office spaces, school classes and stores.

The luminaire body is made of white-coated steel metal. These luminaires are designed for mounting on solid ceilings or suspending on wire pendants. They can be mounted directly on usual inflammable surfaces.

The optical part of the luminaire consists of a microprismatic diffuser creating homogeneous light without visible LED points.

If the luminaire is dimmable, it is dimmable by DALI digital system.

If it is equipped with an autonomous emergency module it is .

Luminaire is equipped with high quality LEDs Samsung powered by drivers only from renowned manufacturers such as Helvar, Tridonic, OSRAM, TCI. The light source and ballast in this luminaire may only be replaced by the manufacturer or his contracted service technician or similarly qualified person.

We have been producing luminaires suitable for illuminating administrative areas, schools, offices and shops for over 20 years. Give your employees, students, patients and customers a well illuminated space thanks to our luminaires.

Installed LED modules in the luminaire 2x LED 15i60-840
Dimension 90x1150x65 mm
Power 39 W *
Luminous flux 2585 lm
Instalation Surface mounted
Mounting holes (AxBxC) 52x1000 mm
Protection IP 20
Color rendering index CRI > 80
Light colour CCT 4000 K
Ambient temperature 25 ˚C
Lifetime LED: 50.000 h L90B20 - 100.000 h L80B50
Weight 1 kg,2
